Description
The YR01829 Benchtop Conductivity Meter is an advanced piece of laboratory equipment designed to deliver precise measurements across various parameters, including conductivity, TDS, salinity, and resistivity. Its 7-inch colored capacitive touch screen offers a modern, user-friendly interface with high resolution and sensitivity. Equipped with intelligent functions like automatic calibration, temperature compensation (ATC), and data storage, this device ensures accuracy and reliability in its readings. The smart electrode status display further aids in maximizing operational accuracy. Featuring USB output and wireless Bluetooth printing options, it facilitates seamless data management and sharing.
Market Price
This type of laboratory equipment typically ranges in price from around $600 to $1,100 on the market, depending on the specific features and capabilities you require. This makes the benchtop conductivity meter a competitively priced option for professionals seeking precision and reliable performance in their measurements.
Frequently Asked Questions
Q: Does the meter support multiple conductivity standards?
A: Yes, the YR01829 Benchtop Conductivity Meter can automatically recognize and calibrate using 8 different conductivity standard solutions, with options for European & USA, and China standards.
Q: Is the data storage capacity sufficient for extensive tests?
A: The device can store up to 2000 sets of test data, which can be easily transferred to a USB memory stick and opened with Excel.
Advantages and Disadvantages
Advantages: The benchtop conductivity meter offers advanced measurement technology, smart functionality, and excellent data management options, making it ideal for various professional applications.
Disadvantages: The initial setup may require a learning curve for those unfamiliar with such devices, and it requires a stable power source of 12V/1A to operate efficiently.
Field Use
In practical scenarios, the YR01829 Benchtop Conductivity Meter is utilized in laboratory settings to measure the conductivity of solutions with high precision. Its temperature compensation feature allows for accurate readings in varying environmental conditions, ensuring reliability in diverse settings.
Recommendations
To maximize the use of the benchtop conductivity meter, it is advisable to regularly calibrate the device using the recommended standard solutions and maintain the electrodes in optimal conditions. Regular updates and maintenance checks will guarantee sustained accuracy and performance.
Features
- 7-inch colored capacitive touch screen with high resolution and sensitivity.
- Intelligent functions including automatic calibration, ATC, and data storage.
- Bluetooth and USB connectivity for data management.
- Smart electrode status display.
- Advanced measurement technology for multiple parameters.
- Auto recognition of standard solutions and multinational calibration options.
- Capacity to store 2000 sets of test data.
Technical Specifications
| Model | YR01829 | |
|
pH
|
Measuring range | (-1.999 ~ 19.999)pH |
| Resolution | 0.1/0.01/0.001 pH | |
| Accuracy | Electrode: ±0.002 pH, Meter: ±0.01 pH | |
| Auto calibration | 1, 2, 3 point | |
| Buffer | Europe & USA, NIST, China standards | |
| Input current | ≤1×10 -12 A | |
| Input impedance | ≥3×10 12Ω | |
| Stability | ±0.002 pH/3h | |
| Temp. compensation | (0 ~ 100)°C, auto or manual | |
|
mV
|
Measuring range | -1999.9mV ~ 0 ~ 1999.9mV |
| Resolution | 0.1 mV | |
| Accuracy | ±0.03% FS | |
|
Cond.
|
Measuring range
|
Conductivity |
| (0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
| (200~2000)μS/cm, (2.00~20.00)mS/cm | ||
| (20.0~200.0)mS/cm | ||
| (200~2000)mS/cm (K=10) | ||
| TDS: (0 ~ 100)g/L | ||
| Salinity: (0 ~ 100)ppt | ||
| Resistivity: (0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1/1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. compensation range | (0 ~ 100)°C, auto Electrode constant 0.1/0.5/1/5/10/50/100 cm -1 | |
| Reference Temp. | 25°C, 20°C, 18°C | |
|
Temp.
|
Range | (-10 ~ 110)°C |
| Resolution | 0.1°C | |
| Accuracy | 5 ~ 60°C:±0.4°C Others: ±0.8°C | |
|
Other
|
Display | 7-inch colored capacitive touch screen |
| Data storage | 1000 sets | |
| Power | 12V/1A | |
| Output | USB | |
| Ambient Temp. | 15 ~ 30 °C | |
| Ambient Humidity | ≤85% | |
| IP grade | IP54 | |
| Dimensions/N.W. | 215×170×37mm/600g | |
| Shipping Size/G.W. | 470x430x72mm/3kg | |
