Description
The Portable Conductivity/DO Meter YR06382 is an advanced instrument designed for precise measurement of conductivity and dissolved oxygen levels in a variety of settings. Featuring a large LCD screen with controllable backlight, this meter integrates intelligent functions such as automatic calibration, temperature compensation, data storage, and more. With its advanced conductivity measurement technology and polarographic DO electrode, it ensures rapid and accurate readings, making it an essential tool for professionals in water quality testing and environmental monitoring.
Market Price
In the market, the price for advanced portable conductivity and DO meters ranges between $500 and $800. This pricing reflects the product’s cutting-edge technology, comprehensive features, and reliable brand reputation. Considering these factors, investing in the YR06382 will provide excellent value for those requiring precise and dependable measurements.
Frequently Asked Questions
Q: How long does the polarization time take for DO measurements?
A: The YR06382 features a short polarization time of only 3 to 5 minutes.
Q: What is the data storage capacity?
A: This meter can store up to 200 sets of data, allowing for thorough analysis and comparison over time.
Advantages and Disadvantages
The YR06382 offers several advantages, including its ease of use, compact design, and multifunctionality, making it ideal for fieldwork. However, one potential downside is that it requires two AA batteries, needing periodic replacement.
Field Use
This product is particularly beneficial in environments where quick and accurate water quality assessments are crucial, such as in laboratories or during fieldwork in remote locations. Its rugged design and multifunctional capabilities allow users to seamlessly switch between conductivity, TDS, salinity, and resistivity measurements.
Recommendations
To maximize the use of this meter, it is recommended to regularly calibrate the device and periodically check and replace the batteries to ensure optimal performance. Additionally, storing the instrument in a dry, cool place will extend its lifespan.
Features
- Large LCD screen with adjustable backlight
- Automatic calibration and temperature compensation
- Data storage capacity for 200 sets
- Robust design with an IP57 rating for dust and water resistance
- Utilizes polarographic DO electrode technology
Technical Specifications
| Model | YR06382 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~19.99)μS/cm | ||
| (20.0~199.9)μS/cm | ||
| (200~1999)S/cm | ||
| (2.00~19.99)mS/cm | ||
| (20.0~199.9)mS/cm | ||
| TDS:(0~100)g/L | ||
| Salinity:(0~100)ppt | ||
| Resistivity:(0~100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS, Overall:±1.5% FS | |
| Temp. compensation | (0~100)ºC(Auto/manual) | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
|
DO
|
Measuring range | (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp. compensation | (0 ~ 45)ºC (auto) | |
| Salinity compensation | (0 ~ 45) ppt (auto) | |
| Pressure compensation | (66 ~ 200) kPa (manual) | |
| Auto calibration | Air saturated by water, water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Measuring range | (0 ~ 100)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Data storage | 200 sets |
| Power | Two AA batteries (1.5V x2) | |
| Ambient Temp. | 5 ~ 35 ºC | |
| Ambient humidity | ≤85% | |
| IP grade | IP57 Dustproof and waterproof | |
| Dimensions/N.W. | (65×120×31)mm/180g | |
| Shipping size/G.W. | (460×300×55)mm/1Kg | |
