Description
The Benchtop Conductivity/DO Meter YR06384 is a state-of-the-art device engineered for accurate measurements in both laboratory and industrial settings. Featuring a 7-inch colored capacitive touch screen, it provides high resolution and sensitivity, ensuring effortless operation. Equipped with an intelligent microprocessor, it automates tasks like calibration and temperature compensation, thereby enhancing user productivity. The meter boasts a data storage capacity of up to 1000 sets, with easy data transfer via USB or Bluetooth for comprehensive analysis and convenience. This versatility makes it an indispensable tool for professionals across various industries.
Market Price
The Benchtop Conductivity/DO Meter YR06384 is competitively priced within the high-precision device market, generally ranging from around $1200 to $2100. This pricing reflects the sophisticated technology and extensive capabilities crucial for professionals who demand precise and dependable conductivity and DO measurements. For a customized quote tailored to your specific needs, we encourage you to request an estimate through our Kalstein Plus platform.
Frequently Asked Questions
What is the calibration process for the YR06384? The YR06384 employs an automatic calibration process, ensuring precision while reducing maintenance effort.
Can the data be transferred to a computer? Absolutely. The device allows seamless data transfer via USB or Bluetooth, offering a flexible and convenient data management solution.
Advantages and Disadvantages
Advantages:
- High-resolution touch screen enables easy navigation.
- Automatic calibration and compensation features streamline operations.
- Versatile measurement modes accommodate a broad spectrum of applications.
- Effortless wireless data transfer via Bluetooth.
- Significant data storage capacity enhances usability.
Disadvantages:
- Initial investment is higher compared to basic meters.
- Regular calibration is necessary to maintain optimal performance.
Field Use
The Benchtop Conductivity/DO Meter YR06384 is essential for applications such as water quality analysis, environmental monitoring, and various industrial processes. Its capability to measure conductivity, TDS, and DO effectively equips researchers and field technicians with a reliable tool. Designed with robust construction and quick response times, it guarantees consistent performance across different environments.
Recommendations
To ensure the YR06384 functions at its best, regular calibration with suitable standards is recommended. Proper cleaning and maintenance of electrodes post-use can significantly prolong the device’s lifespan. Keeping the firmware updated with manufacturer-provided enhancements will ensure continued optimal functionality.
Features
- 7-inch colored capacitive touch screen.
- Intelligent microprocessor with automatic functionalities.
- Bluetooth and USB data transfer capabilities.
- Smart electrode status display for improved accuracy.
- Data storage capacity of 1000 sets.
Technical Specifications
| Model | YR06384 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
| (200~2000)μS/cm, (2.00~20.00)mS/cm | ||
| (20.0~200.0)mS/cm, | ||
| (200~2000)mS/cm (K=10) | ||
| TDS:(0 ~ 100)g/L | ||
| Salinity:(0 ~ 100)ppt | ||
| Resistivity:(0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. compensation range | (0 ~ 50)ºC, auto | |
| Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
| Reference Temp. | 25ºC,20ºC,18ºC | |
|
DO
|
Measuring range | (0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm) 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp compensation | (0 ~ 45)ºC, auto | |
| Salinity compensation | (0 ~ 45) ppt, auto | |
| Pressure compensation | (80 ~ 105) kPa, auto | |
| Auto calibration | Air saturated by water; water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Range | (-10 ~ 110)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Display | 7-inch colored capacitive touch screen |
| Data storage | 1000 sets | |
| Power | 12V/1A | |
| Output | USB, RS232, Bluetooth | |
| Ambient Temp. | 15 ~ 30 ºC | |
| Ambient Humidity | ≤85% | |
| IP grade | IP54 | |
| Dimensions/N.W. | 240×170×70mm/600g | |
| Shipping Size/G.W. | 470x430x85mm/2.6kg | |
