Stainless Steel Small Ultra Low Temperature Freezer YR05313
Stainless Steel Small Ultra Low Temperature Freezer YR05313 — equipo de laboratorio Kalstein con especificaciones técnicas, características avanzadas y soluciones profesionales certificadas para uso científico.
The Stainless Steel Small Ultra Low Temperature Freezer YR05313 is an exceptional lab and hospital equipment designed for ultra-low temperature preservation needs. With a temperature range adjustable from -40°C to -86°C, it ensures precise and stable conditions for your sensitive samples. Its sturdy stainless steel construction, along with a superior thermal insulation performance provided by a silicone door seal, makes it a reliable choice for any laboratory environment. The digital display further enhances usability, offering a clear and easy view of the freezer's status, while the safety door lock and alarm systems safeguard your samples against unexpected disturbances.
Market Price
In the current market, ultra-low temperature freezers similar to the YR05313 model are typically priced in the range of $4,100 to $4,900 USD. This pricing reflects the advanced features and reliable performance that such equipment offers to laboratories and hospitals worldwide.
Frequently Asked Questions
- What is the power consumption of the freezer? The freezer consumes approximately 3.8 kWh/24h, making it energy efficient for its category.
- Is the freezer noise level manageable for a lab environment? Yes, the ultra-low temperature freezer operates at a noise level of 50dB, ensuring minimal disruption in a work setting.
Advantages and Disadvantages
- Advantages:
- Excellent temperature stability with advanced microprocessor control.
- Strong build with stainless steel interior for durability.
- Energy-efficient with low power consumption.
- Disadvantages:
- Manual defrost may require periodic attention.
- Initial cost can be high, though offset by long-term reliability and efficiency.
Product Usage in the Field
The YR05313 is ideally used in laboratories for the long-term storage of biological samples, enzymes, and other temperature-sensitive materials. Its robust cooling system and reliable temperature control make it suitable for preserving samples under ultra-low temperatures without the threat of freezer burn or ice build-up.
Recommendations
For optimal performance, ensure the freezer is placed in a well-ventilated area to maintain efficiency and prolong the lifespan of its components. Regularly inspect the door seals and clean the interior for consistent performance. Consideration for a CO2 or LN2 backup system is advisable to protect your samples during power outages.
Features
- Capacity: 105L, suitable for large volume storage.
- PTC temperature sensor ensures accurate readings.
- Imported compressor brand CUBIGEL for reliable cooling.
- Robust alarm system for high/low temperature, sensor errors, and thermostat issues.
Technical Specifications
| Model | YR05313 | |
| Specificaitons | Shelf/drawer QTY | / |
| Cooling | Direct cooling | |
| Defrost | Manual | |
| Refrigerant | Mixed-gas | |
| Power Consumption(kWh/24h) | 3.8 | |
| Noise(db) | 50 | |
| Ambient temperature(℃) | 10~32℃ | |
| Temperature range(℃) | -40~-86℃ | |
| Cooling system | Compressor brand/QTY | CUBIGEL/1 |
| Sensor | PTC | |
| Temperature controller | Microprocessor | |
| Display | Digital display | |
| Power | Voltage/frequency(V/Hz) | 220/50Hz |
| Power(W) | 500W | |
| Current(A) | 2.9 | |
| Material | Inside material | Stainless steel |
| Outside material | Color sprayed steel | |
| Insulation | PURF | |
| Size | Capacity(L/cu.ft) | 105/3.70 |
| NT./GT.(kg) | 63.7/68.5 | |
| Exterior size(W*D*H)(mm) | 680*580*935 | |
| Interior size(W*D*H)(mm) | 480*380*665 | |
| Package size(W*D*H)(mm) | 770*705*1090 | |
| CBM | 0.59 | |
| 20GP/40GP/40HQ | 24/51/51 | |
| Frozen Racks | Racks | 4(11X1,6X1) |
| Boxes (2 Inches) | 34 | |
| Samples(2ml) | 3400 | |
| Alarm | High/low temperature | Y |
| Power failure | / | |
| Abnormal voltage | / | |
| Sensor error | Y | |
| Filter screen check | / | |
| Thermostat failure | Y | |
| Low battery | / | |
| Condenser clean | / | |
| High ambient temperature | / | |
| Door ajar | / | |
| Power failure backup system(alarm) | 12h | |
| Accessories | Castor | Y |
| Inside door | / | |
| Test hole QTY/diameter | 1/25MM | |
| USB port | / | |
| Chart recorder | / | |
| Data logger | Optional | |
| Remote alarm port | / | |
| Optional | CO2 back up system | Optional |
| LN2 back up system | Optional | |
| Other | Certification | ISO.CE |
Technical specifications
| Weight | 88 kg |
|---|---|
| Manufacturer | Kalstein |
