Portable Desktop spectrophotometer YR05487
Portable Desktop spectrophotometer YR05487 — equipo de laboratorio Kalstein con especificaciones técnicas, características avanzadas y soluciones profesionales certificadas para uso científico.
The Portable Desktop Spectrophotometer YR05487 is a versatile color measurement instrument developed by Kalstein, renowned for its cutting-edge spectroscopic technology. This spectrophotometer integrates a silicon photodiode array (40 groups in double rows) and an imported white board, which work together to enhance measurement speed and operational convenience. The device's innovative rotating and pressing structure streamlines the testing process, making it ideal for laboratories requiring precise color analysis. With its superior accuracy, reflected in repeatability and inner error metrics, the YR05487 ensures reliable performance across various industries.
Market Price
The Portable Desktop Spectrophotometer YR05487 is known for its advanced capabilities and stable performance. In the market, similar premium spectrophotometers range from approximately $7,500 to $8,500. This price range reflects both the technological sophistication of the tool and its efficient application in professional settings. For precise pricing and to request a quote tailored to your needs, we encourage potential buyers to use the Kalstein Plus platform for auto-generated quotations.
Frequently Asked Questions
Q: What industries benefit most from the YR05487 spectrophotometer?
A: The device is perfect for textile, garment printing, dyeing, plastics, electronics, and ceramics industries.
Q: Can this spectrophotometer measure fluorescence samples?
A: Yes, the YR05487 is capable of measuring fluorescence samples, enhancing its versatility in research and quality control.
Advantages and Disadvantages
Advantages: The YR05487 offers unparalleled measurement precision, a user-friendly interface with a 7-inch touch screen, and diverse color space support. It comes equipped with a camera positioning system, ensuring accurate measurements.
Disadvantages: Due to its advanced features, it may require a learning curve for users less familiar with spectrophotometry. The initial investment might be high for small-scale operations.
Field Use
The YR05487 spectrophotometer excels in field use, particularly in environments requiring stringent color quality controls. Its robust build and portability allow for easy transportation between testing sites in industries such as textiles and ceramics, ensuring that production standards meet international quality benchmarks. The camera locating feature enhances accuracy, facilitating real-time adjustments and decisions during production processes.
Recommendations
To maximize the performance of the YR05487, regular calibration with the provided white and black calibration cavity is recommended. This ensures continued measurement precision. Utilizing the sectional color management software enables users to generate detailed reports, aiding in compliance and enhancing color consistency across manufacturing batches.
Features
- Adopts international d/8 optical geometry
- Equipped with a silicon photodiode array sensor
- Comprehensive color space and observation light sources
- Built-in camera for precise locating
- Industrial-grade 7-inch HD touch screen
Technical Specifications
| Model | YR05487 |
| Optical Geometry | D/8(diffused illumination, 8-degree viewing angle) |
| SCI (specular component included)/SCE (specular component excluded) ; Include UV / excluded UV light source | |
| Comply to CIE No.15，GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7 | |
| Characteristic | Customized aperture,good for horizontal or vertical measurement, wider adaptability; |
| Suitable for precise color measurement and quality control in textile and garment printing and dyeing, plastic electronics, ceramics and other industries; | |
| Integrating Sphere Size | Φ40mm |
| Light Source | Combined full spectrum LED light source |
| Spectrophotometric Mode | Flat Grating |
| Sensors | Silicon photodiode array (double row 40 groups) |
| Wavelength Range | 400~700nm |
| Wavelength Interval | 10nm |
| Semiband Width | 10nm |
| Measured Reflectance Range | 0~200% |
| Measuring Aperture | Customized single aperture:MAV:Φ8mm/Φ10mm;SAV:Φ4mm/Φ5mm |
| Specular Component | SCI/SCE |
| Color Space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,βxy,Munsell(C/2) |
| Color Difference Formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00 |
| Other Colorimetric Index | WI(ASTM E313,CIE/ISO,AATCC,Hunter)， |
| YI(ASTM D1925,ASTM 313), | |
| Staining Fastness, Color Fastness, Color Strength, Opacity | |
| 8° Glossiness,555 tone classification | |
| Observer Angle | 2°/10° |
| Illuminant | D65,A,C,D50,F2(CWF),F7(DLF),F10(TPL5),F11(TL84),F12(TL83/U30) |
| Displayed Data | Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Simulation, Color Offset |
| Measuring Time | About 1.5s (Measure SCI & SCE about 3.2s) |
| Repeatability | Chromaticity value: MAV/SCI, within ΔE*ab 0.025 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration) |
| Inter-instrument Error | MAV/SCI, Within ΔE*ab 0.2 (Average for 12 BCRA Series II color tiles) |
| Measurement Mode | Single Measurement, Average Measurement(2-99times) |
| Locating Method | Camera Locating |
| Dimension | L*W*H=370X240X260mm |
| Weight | About 7.8kg |
| Battery | AC 24V, 3A Power adapter power supply |
| Illuminant Life Span | 5 years, more than 3 million times measurements |
| Display | 7-inch TFT color LCD, Capacitive Touch Screen |
| Data Port | USB, trigger switch interface |
| Data Storage | Standard 1000 Pcs, Sample 20000 Pcs |
| Language | Simplified Chinese, English, Traditional Chinese |
| Operating Environment | 0~40℃, 0~85%RH (no condensing), Altitude < 2000m |
| Storage Environment | -20~50℃, 0~85%RH (no condensing) |
| Standard Accessory | Power Adapter, USB Cable, User Guide, PC Software(Download from office website), White and Black Calibration Cavity, Protective Cover, Aperture (Optional Aperture) |
| Optional Accessory | Micro Printer, Foot Switch, Rotating Bracket |
| Notes | Technical parameters are only for reference, subject to the actual sale of the product |
Technical specifications
| Weight | 12 kg |
|---|---|
| Manufacturer | Kalstein |
Image gallery
Video Portable Desktop spectrophotometer YR05487
Frequently asked questions
How to know the prices of Portable Desktop spectrophotometer YR05487?
To know the price of Portable Desktop spectrophotometer YR05487, please send us an email with your request through the contact form AQUI.
What are the delivery times for Portable Desktop spectrophotometer YR05487?
Delivery time depends on stock availability and freight type (air or sea). In stock: air 15-30 days, sea 45-60 days. Out of stock: air 30-60 days, sea 60-90 days.
How to make a purchase of Portable Desktop spectrophotometer YR05487?
You can buy by email ([email protected]), phone (+33 (0) 1 70 39 26 50) or through the official Kalstein website in your country.
How does the warranty work for Portable Desktop spectrophotometer YR05487?
All Kalstein equipment comes with a 1-year warranty against manufacturing defects. The warranty does not cover damage from improper installation or misuse. See our «terms and conditions» AQUI.
Can I request a quote online for Portable Desktop spectrophotometer YR05487?
Yes, you can request a quote for the Kalstein equipment you are interested in directly from our official website. Click AQUI.
