Doppler Fetal Monitor YR02180
Doppler Fetal Monitor YR02180 — equipo de laboratorio Kalstein con especificaciones técnicas, características avanzadas y soluciones profesionales certificadas para uso científico.
The Doppler Fetal Monitor YR02180 is a state-of-the-art patient monitoring device designed specifically for high-pressure environments such as operating theatres and intensive care units. With its 17-inch LCD screen and semi-modular design, this monitor offers comprehensive monitoring capabilities through its six standard parameters: ECG, SpO2, TEMP, NIBP, RESP, and PR/HR. Optional features such as a touchscreen interface, extended ECG leads, and diverse mounting solutions make it adaptable to various clinical settings, thereby meeting diverse healthcare needs efficiently.
Market Price
The market price for the Doppler Fetal Monitor YR02180 typically ranges between $3,200 and $4,000. This competitive pricing reflects its advanced design and capability array, making it a worthwhile investment for healthcare facilities looking to enhance patient care. For an official quote, you're encouraged to utilize the Kalstein Plus platform, which offers immediate assistance in obtaining a competitive offer.
Frequently Asked Questions
What parameters are standard with the Doppler Fetal Monitor YR02180? The monitor comes equipped with six standard parameters: ECG, SpO2, TEMP, NIBP, RESP, and PR/HR.
Can the monitor be tailored to suit different clinical environments? Absolutely, with the inclusion of optional features such as a touchscreen, extended ECG leads, and versatile mounting options, it can be customized to fit a variety of settings.
Advantages and Disadvantages
Advantages: The Doppler Fetal Monitor YR02180 is highly adaptable and offers extensive parameter capabilities, which ensures comprehensive patient data collection. It is particularly useful in multiparameter monitoring environments.
Disadvantages: The initial setup might require technical expertise, and adding optional features can incur additional costs.
Field Use
The Doppler Fetal Monitor YR02180 proves ideal in high-stakes environments like intensive care units where precise monitoring is essential. Its semi-modular structure allows for seamless adaptation to various patient care scenarios, ensuring reliable performance across diverse clinical demands.
Recommendations
To optimize the performance of the Doppler Fetal Monitor YR02180, adhere to regular maintenance and calibration as advised by the manufacturer. Providing training sessions for healthcare staff can also be beneficial, helping them fully understand and utilize all the device’s functionalities.
Features
- 17-inch LCD screen with a semi-modular configuration
- Standard parameters: ECG, SpO2, TEMP, NIBP, RESP, PR/HR
- Optional features include a touchscreen, extended ECG leads, and various mounting solutions
- Suitable for use in operating theatres and ICU environments
Technical Specifications
| Model | YR02180 | |
ECG | Lead mode | 5 Leads(RA,LA,LL,RL,V) |
| Connection method | I, II, III,AVR,AVL,AVF,V | |
| Lead Mode | 3 Leads (RA,LA,LL) | |
| Connection method | I, II,III | |
| Gain | x250, x500, x1000, x2000 | |
| Accuracy | ±5% | |
| Resolution | 1bpm | |
| Sensitivity | >200(uVp-p) | |
| Differential input impedance | ≥5MΩ | |
| ST segment Monitoring Range | ||
| Measure Range | -1.0~+1.0mV | |
| Measure Accuracy | -0.8mV~+0.8mV | |
Heart Rate | Measuring range | 40~240bpm |
| Accuracy | ±3bpm | |
| Resolution | 1bpm | |
| Sensitivity | >200UVp-p | |
Respiration | Method | Impedance between R-F(RA-LL) |
| Measuring Impedance Range | 0.3~3.0 MΩ | |
| Bandwidth | 0.1~2.5Hz | |
| Respiration Rate | Adult: 7~120BrPM | |
| Neo/Ped | 7~150BrPM | |
| Resolution | 1 BrPM | |
| Accuracy | ±2 BrPM | |
NIBP | Method | Oscillometric |
| Measuring Interval in AUTO Mode | 1,2,3,4,5,10,15,30,60,90,120,180,240(Min) | |
| Measuring Period in STAT Mode | 5 Min | |
| Pulse Rate Range | 40~240bpm / 40~150bpm | |
| Alarm Type | SYS, DIA, MEAN | |
| Resolution | ||
| Pressure | 1mmHg | |
SPO2 | Display | Number of SPO2,waveform of capacity,Pulse |
| Measuring range | 0~100% | |
| Resolution | 1% | |
| Accuracy | 70~99% (±2%) | |
| Pulse rate range | 0~300bpm | |
TEMP | Channel | 2 |
| Measuring and Alarm Range | 0~50ºC | |
| Resolution | 0.1ºC | |
| Accuracy | 0.1ºC | |
| Actualization interval | about 1 Second. | |
| Average Time Constant | <10 Second. | |
Technical specifications
| Dimensions | L 57 × W 39 × H 53.5 cm |
|---|---|
| Weight | 8 kg |
| Manufacturer | Kalstein |
Frequently asked questions
How to know the prices of Doppler Fetal Monitor YR02180?
To know the price of Doppler Fetal Monitor YR02180, please send us an email with your request through the contact form AQUI.
What are the delivery times for Doppler Fetal Monitor YR02180?
Delivery time depends on stock availability and freight type (air or sea). In stock: air 15-30 days, sea 45-60 days. Out of stock: air 30-60 days, sea 60-90 days.
How to make a purchase of Doppler Fetal Monitor YR02180?
You can buy by email ([email protected]), phone (+33 (0) 1 70 39 26 50) or through the official Kalstein website in your country.
How does the warranty work for Doppler Fetal Monitor YR02180?
All Kalstein equipment comes with a 1-year warranty against manufacturing defects. The warranty does not cover damage from improper installation or misuse. See our «terms and conditions» AQUI.
Can I request a quote online for Doppler Fetal Monitor YR02180?
Yes, you can request a quote for the Kalstein equipment you are interested in directly from our official website. Click AQUI.
